Horizontal bracket, bottom left / top right (40 mm) ZW-TRB/L1M

Item no. ZW-TRB · EAN 2010000052952

horizontal
for hinge ZW-TRS-1

Material: ZnAl

In brief

Horizontal 40 mm bracket for the bottom left and top right positions.
ZnAl alloy, assigned to hinge ZW-TRS-1.
The 36 mm version is ZW-TRB/L1.
The size is recognised by the letter M in the designation.

Data sheet PDF, p. 7

Check price and availability Request a quote

Prices and stock levels are in the B2B shop. Series orders and non-standard versions are quoted individually.

Horizontal bracket, bottom left / top right (40 mm) ZW-TRB/L1M – how to choose the right one

ZW-TRB/L1M is the 40 mm version of the horizontal ZnAl alloy bracket, intended for the bottom left and top right mounting points with hinge ZW-TRS-1.

The family of horizontal ZW-TRB brackets comprises eight part numbers: four position arrangements, each in two sizes. The designation is therefore read in two steps – first the letter and digit defining the position, then the M suffix for the wider version.

When ordering it is enough to state the full marking. The description of the position alone does not settle it, because each arrangement comes in two dimensional versions.

How to choose a hinge for the door weight and the mounting method – we explained it in the selection guide for this category.

Where it works

Installations built in the 40 mm size
Bottom left mounting point of hinge ZW-TRS-1
Top right points in the cabinet
Making up fittings after dismantling

Manufacturing

Custom projects (R&D)

Catalogue

All categories: Hardware, fittings

Frequently asked questions

Have not found your answer? Give the door weight and the mounting method – we will select the hinge and the brackets.

Ask a question

How many horizontal ZW-TRB brackets are on offer?

Eight. Four position arrangements – two diagonals in two variants – each in the 36 and 40 mm versions.

Does the M suffix always mean 40 mm?

In this family, yes: part numbers with M are the 40 mm versions, those without it are 36 mm. For a non-standard order, the dimension is worth confirming with an AiFO advisor.
